Safe 6m height indoor wheelchair hydraulic lift factory

  • *Model:THHL-2
  • *Lift height:6000mm
  • *Work height:7050mm
  • *Load capacity:400kg
  • *Weight:1500kg
  • *Platform size:1000*1000mm or customized
  • *Overall size:1000*1000mm or customized
  • *Power supply:220V 50Hz Single Phase or customized
  • *Brand:Tuhe

Its hydraulic or screw system provides passengers with smooth and comfortable transportation and different safety devices eliminate every hidden risk.The landing door installed on each floor where operator entrance, which can prevent falling down. Standard height 900mm,There will be a fixed rubber ramp, for users easy coming in and out. In this way, it no need dig a pit.




The lift will be stopped at once if it touches any obstacle when going down, especially to protect the children if he enters accidentally.Electromagnetic lock makes the lift won't work when the door is open, the lift can rise only when all doors are completely closed. Guarantee the safety of operator.



➤Emergency lowering system: When there is no power supply or malfunction, the elevator is lowered manually.



➤Suitable for new large-scale residential districts and areas with dense land resources.



➤Control panel

Multi-function button box: with"Power. Lock. Up. Down. Emergeny Stop" buttons


Anti-skid auto flap

Auto flap safety working range: max 75° to prevent the wheelchair from moving outside

Remote control

Optional as per your actual needs

Handrail on guardrail

Keep people's safety


The lift will be stopped at once if it touches any obstacle when going down, especially to protect the children if he enters accidentally.Electromagnetic lock makes the lift won't work when the door is open, the lift can rise only when all doors are completely closed. Guarantee the safety of operator.


We offer free installation video when we ship the elevator



If you want to ask anything just fill in the form below and send us. We will contact you within 12 hours.
